The 1112 series stainless steel butterfly valve metal-metal, equiped with either a spring return or double-acting ACTREG pneumatic actuator, features a CF8M body and disc. It is a wafer type PN10/16 and ANSI 150.
| Specification | Value |
|---|---|
| Option certificate 3.1 | Yes |
| Maximum delta P (bar) | 10 |
| Operating angle (°) | 90 |
| Shaft/stem matérial | Stainless steel 316 |
| Adjustable limit screws | Yes |
| Lockable | No |
| ATEX compatible | Yes |
| DN | DN50 - 2'' |
| Face to Face (mm) | 68.0 |
| Seat | Metal/metal |
| Body material | Stainless steel CF8M (1.4408) |
| ATEX protection mode | Ex c |
| Number of ways | 2 |
| Disc material | Stainless steel CF8M |
| Position | Normally closed |
| PS (bar) | 16 |
| Connections | Between flanges PN10/16 #150 |
| Surface temperature | TX |
| Pneumatic actuator type | Double acting |
| Warranty period | 2 years |
| CE | Risk category III |
| Range | TTV |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN50 - 2'' Double acting | 263034015100 | S1003510 |
€524.03
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN50 - 2'' Spring return | 263034016101 | S1003511 |
€560.10
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN65 - 2''1/2 Double acting | 263035015101 | S1003512 |
€617.39
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN65 - 2''1/2 Spring return | 263035016102 | S1003513 |
€672.56
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN80 - 3'' Double acting | 263036015101 | S1003514 |
€670.43
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN80 - 3'' Spring return | 263036016102 | S1003515 |
€723.47
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN100 - 4'' Double acting | 263037015102 | S1003516 |
€777.57
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN100 - 4'' Spring return | 263037016103 | S1003517 |
€887.40
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN125 - 5'' Double acting | 263038015102 | S1003518 |
€1,044.89
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN125 - 5'' Spring return | 263038016104 | S1003519 |
€1,111.80
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN150 - 6'' Double acting | 263039015103 | S1003520 |
€1,173.24
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN150 - 6'' Spring return | 263039016105 | S1003521 |
€1,434.20
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN200 - 8'' Double acting | 263040015104 | S1003522 |
€1,531.81
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) DN200 - 8'' Spring return | 263040016106 | S1003523 |
€1,862.79
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) Double acting DN250 - 10'' | 263041015105 | S1003524 |
€2,728.39
(excl. btw)
|
add to cart |
| Between flanges PN10/16 #150 Stainless steel CF8M (1.4408) Spring return DN250 - 10'' | 263041016106 | S1003525 |
€2,893.87
(excl. btw)
|
add to cart |
